Suoer 3000VA 24V DC to 220V AC 3KVA Pure Sine Wave Off Grid Hybrid Solar Inverter with 50A Charger and PWM Solar Controller

PL-3KVA

Low Frequency Hybrid Inverter

Features:

64-bits DSP Intelligent control chipset.

LED and LCD display with multi-function,Real time display of dynamic values.

Built-in automatic 50A AC charger and automatic AC mains switcher. Switch time ≤5ms.

Built-in 50A PWM solar charging controller,maximize the solar energy.

High Transfer efficiency is above 90％.

Continuous stable pure sine wave output with built-in AVR stablizer.

3 times surge power,excellent loading capability.

INQUIRE NOW

SEND ENQUIRY

Specifications

Model	PL-1KVA	PL-2KVA	PL-3KVA	PL-4KVA	PL-5KVA	PL-6KVA
Rated capacity	1000	2000	3000	4000	5000	6000
Input
Voltage	(147-275)VAC	(170-275)VAC
Frequency	(50Hz/60Hz±5Hz）Auto
Output
Voltage	AC220V±5%(battery mode)
Frequency	50Hz/60Hz±1%(battery mode)
Waveform	pure sine wave
Efficiency	≥90%
Solar input voltage	24V(PWM)<55VDC 12V(PWM)<30VDC	(MPPT)<150VDC / 48V(PWM)<100VDC / 24V(PWM)<55VDC
Solar charge current	30A	60A		80A
Battery	Optional
Battery rated voltage	12/24VDC	24/48VDC				48VDC
Max AC charge current	5~15A	5~50A
Protect	Overload/short circuit/battery high/low voltage/AC inputhigh/low voltage protection
Conversion way	Interacive
Capacity of overload	110%~120%turn to bypass after 30secs, 160% maintain 300ms and then shut down
Operating environment
Temperature	-20±75℃
Humidity	10%-90%
Size:LWH(mm)	280130290	397154474		456161513
G.W(kg)	18(2pcs)	20.5(1pcs)	23(1pcs)	25.9(1pcs)	27.4(1pcs)	29.5(1pcs)

Low frequency pure sine wave inverter,Built in 50A PWM Solar Controller&Battery Charger.Based on transformer technology,strong loading capacity.Used for all kinds of home/office equipments,solar power system.

Suoer 3000VA 24V DC to 220V AC 3KVA Pure Sine Wave Off Grid Hybrid Solar Inverter with 50A Charger and PWM Solar Controller

PL-3KVA

Features:

SEND ENQUIRY

Specifications

Product Photos
