Suoer 1000w 220v 12v dc ac pure sine wave inverter with USB charging interface

FPC-1000A

Pure Sine Wave Inverter

Features:

Features

1. High conversion efficiency, smart soft start function.

2. Multiple safe protections

3. Input and output are completely independent

4. Smart, light,and portable,designed for home use.

5. Universal socket, suitable for all kinds of plugs

6. Pure sine waveform output

7. Applicable for resistive/sensitive loads

8. High-procision voltage stability technology

9. Aerospace-grade silence technology

10. Cooler of fan and working status are intellectually controlled by MCU, which mostly prolongs its service life and helps to save the power consumption

11. Gained CE,CTA,ISO,RoSH certificates guaranteed.

12. 26 years' experience in home power supply industry

13. 100% pure sine wave output waveform: designed for sensitive loads(resistive load).

14. With the technology of CPU centralized control and SMD inside.

15. True sine wave output (Total Harmonic Distortion(THD) < 3%)

Protections

5 safe protections are designed to ensure the safety of the power inverter and theelectric appliances ,including overload protection, overvoltage protection, low voltage protection, high temperature protection, output short circuit protection.

INQUIRE NOW

SEND ENQUIRY

Specifications

Model	FPC-1000A	FPC-1000B	FPC-1000F
Peak power	2000W(1S)
Rated power	1000W
Output waveform	Pure sine wave
Output voltage	220V/230±5V
Harmonic distortion	<3%(Impedance load)
Output frequency	50Hz(or 60Hz)
Standby current	<0.9A	<0.4A	<0.3A
Conversion efficiency	80%-85%
Rated voltage	12V	24V	48V
Maximum input current	120A	60A	30A
Input voltage range	9V-16V	18V-32V	38V-62V
Under voltage protection	9.5V±0.5V	19.9V±0.2V	40.2V±0.2V
Under voltage tip	10.2V±0.5V	20.9V±0.2V	42.2V±0.2V
Under pressure recovery	12.5V±0.5V	24.7V±0.2V	48.2V±0.2V
Over voltage protection	15V±0.5V	30.2V±0.2V	60.4V±0.2V
Over voltage recovery	14.8V±0.5V	29.8V±0.2V	60.1V±0.2V
High temperature protection	Buzzer/LED warning
Output short circuit protection	Buzzer/LED warning

Output overload	Smart control
Load power factor	0.98
USB Output	5V 1A
Battery reverse protection	No
Cooling way	Temperature control
Working temperature	-20~60°C
Storage temperature	-20~80°C
Working humidity	10~90%(No condensation)
Size/CTN	44.539.532.5cm
G.W./CTN	14.5kg
Packing	4Pcs/CTN

Video Tutorial

This pure sine wave inverter is extraordinarily designed for home use,which can convert DC 12V/24V of portable power supply to AC 110V/220V/230V and it works for almost all the household electrical resistive appliances such as MP3/MP4 player,cell phone, laptop, emergency light, electric blanket, electric shaver, electric cooker,digital camera, digital video,CD/DVD player,XBOX/PS4 game player, ordinary electric lamps, bulb,fluoresent light, rice cooker,electric iron,desktop computer, graphoscope,fax machines, printers, LCD TV, electric fans, cell phone chargers, electric iron , drinking fountain,hair dryer and so on.(Note:Only pure sine wave inverter can run sensitive electric appliances that are including refrigerator, washing machine,microwave oven, induction cooker, electric drill,compressor,air conditioner,mercury lamp, sodium lamp and so on).
